FPGA 07/13 · Timing Claude — Timing Closure

The problem

FPGAs often suffer from sporadic board failures or missed performance targets because timing violations are ignored or misdiagnosed. Developers frequently waste days manually inserting pipeline registers across the entire design instead of targeting the specific paths causing negative slack.

What it does

• Analyzes post-route timing reports to classify violations as setup (frequency-dependent) or hold (functional defects).
• Executes a report-driven pipelining loop, identifying the worst path and inserting a single register at the transition point to meet targets without bloating area.
• Identifies and constrains Clock Domain Crossing (CDC) paths using two-flip-flop synchronizers or handshakes with appropriate asynchronous markings.
• Audits constraint files for missing clock definitions and applies false-path or multicycle markings to prevent artificial analysis bottlenecks.
• Verifies system-level bottlenecks to ensure optimization effort isn't wasted on a core that is gated by a slow host interface.

Frameworks & tools

AMD Vivado, Intel Quartus, Xilinx Design Constraints (XDC), Synopsys Design Constraints (SDC), and Static Timing Analysis (STA) tools.

Why this beats prompting it yourself

General-purpose LLMs often confuse setup and hold remediation strategies, leading to useless clock adjustments for hold violations. This skill enforces a rigorous diagnosis-first workflow, ensuring every CDC path is correctly synchronized and every pipeline stage is quantitatively justified by WNS/TNS improvements.

Use cases

• Resolving negative WNS/WHS after implementation in high-frequency Vivado designs.
• Safely crossing clock domains without risking metastability or false timing alarms.
• Optimizing throughput in compute cores by balancing pipeline depth against fill latency.
• Cleaning up "phantom" timing violations by correctly marking false paths in legacy code.

Known limitations

Requires an existing routed design checkpoint and post-route timing reports to function. It does not perform physical floorplanning or placement-based optimization.
