Stress Testing — Load, Spike, Soak & Breakpoint Plans

Summary

Nothing has been run. This is the plan, the k6 script, and the pass/fail criteria for you to review. The goal is to answer one question: does checkout hold the Black Friday peak on staging? Given your numbers, that means a

smoke run, an

average-load baseline at 120 req/s, and a

stress run at 240 req/s, in that order. A

spike run is optional; it needs a spike level from you. All load uses the

open model (arrival rate), because web traffic keeps arriving whether or not the API is slow.

Confirm before any run

Target and environment: https://staging-api.shopfictional.dev. Is staging shared with other teams tonight? A stress run at 240 req/s will degrade it for anyone else using it.
2. Payments: POST /checkout must hit a payment sandbox, not a real provider. Please confirm.
3.

Data volume: how close are staging's product, user, and order tables to production size? Problems that hide at 1k rows often show up at 1M. This plan writes down whatever gap exists as a limit on the conclusions.
4.

Traffic mix: I assumed 60% browse list / 25% product detail / 10% add to cart / 5% checkout. That is a placeholder. Replace it with the endpoint split from your APM.
5.

Spike level: if you want a spike test, give me the surge you're planning for (for example, the expected traffic when the campaign email goes out).
6.

Load generator: run it from a machine with headroom, in the same location for every run, and keep it the same for future baseline comparisons.

Plan

Stress runs only if average-load passes. If the system fails at normal load, a 2x test produces noise.

Script: checkout-load.js

import http from 'k6/http';
import { check } from 'k6';
import { SharedArray } from 'k6/data';

const BASE = __ENV.BASE_URL;
const PROFILE = __ENV.PROFILE || 'smoke';

// Parameterized data: varied products and users, so caches don't fake the result.
const products = new SharedArray('products', () => JSON.parse(open('./data/products.json')));
const users = new SharedArray('users', () => JSON.parse(open('./data/users.json'))); // staging test accounts + tokens

const arrival = (stages) => ({
  executor: 'ramping-arrival-rate',  // open model
  startRate: 0,
  timeUnit: '1s',
  preAllocatedVUs: 200,
  maxVUs: 1000,
  stages,
});

const PROFILES = {
  smoke: { executor: 'constant-vus', vus: 2, duration: '1m' },
  average: arrival([
    { target: 120, duration: '5m' },
    { target: 120, duration: '30m' },
    { target: 0, duration: '5m' },
  ]),
  stress: arrival([
    { target: 240, duration: '10m' },
    { target: 240, duration: '20m' },
    { target: 0, duration: '5m' },
  ]),
  spike: arrival([
    { target: 120, duration: '2m' },
    { target: Number(__ENV.SPIKE_RPS), duration: '30s' },
    { target: Number(__ENV.SPIKE_RPS), duration: '2m' },
    { target: 120, duration: '30s' },
    { target: 120, duration: '5m' },  // recovery window
  ]),
};

export const options = {
  scenarios: { [PROFILE]: PROFILES[PROFILE] },
  thresholds: {
    // SLO, measured on successful responses so fast errors can't flatter latency
    'http_req_duration{expected_response:true}': ['p(95)<400'],
    http_req_failed: ['rate<0.01'],
    // per-flow visibility: checkout must meet the SLO on its own
    'http_req_duration{flow:checkout}': ['p(95)<400'],
    // generator health: dropped iterations mean the generator couldn't keep the rate
    dropped_iterations: ['count<1'],
  },
};

const pick = (arr) => arr[Math.floor(Math.random() * arr.length)];

export default function () {
  const r = Math.random();
  const user = pick(users);
  const auth = { headers: { Authorization: `Bearer ${user.token}`, 'Content-Type': 'application/json' } };

  if (r < 0.60) {
    const page = 1 + Math.floor(Math.random() * 20);
    const res = http.get(`${BASE}/products?page=${page}`, { tags: { name: 'GET /products', flow: 'browse' } });
    check(res, { 'list 200': (x) => x.status === 200 });
  } else if (r < 0.85) {
    const res = http.get(`${BASE}/products/${pick(products).id}`, { tags: { name: 'GET /products/:id', flow: 'detail' } });
    check(res, { 'detail 200': (x) => x.status === 200 });
  } else if (r < 0.95) {
    const res = http.post(`${BASE}/cart/items`, JSON.stringify({ productId: pick(products).id, qty: 1 }),
      { ...auth, tags: { name: 'POST /cart/items', flow: 'cart' } });
    check(res, { 'cart 2xx': (x) => x.status >= 200 && x.status < 300 });
  } else {
    const add = http.post(`${BASE}/cart/items`, JSON.stringify({ productId: pick(products).id, qty: 1 }),
      { ...auth, tags: { name: 'POST /cart/items', flow: 'checkout' } });
    // Don't fire a dependent request after a failure; under load, errors are expected.
    if (!check(add, { 'checkout: cart 2xx': (x) => x.status >= 200 && x.status < 300 })) return;
    const res = http.post(`${BASE}/checkout`, JSON.stringify({ paymentMethod: 'sandbox_test_card' }),
      { ...auth, tags: { name: 'POST /checkout', flow: 'checkout' } });
    check(res, { 'checkout 2xx': (x) => x.status >= 200 && x.status < 300 });
  }
}

Each iteration is one request, except checkout, which makes two. So the configured arrival rate approximates requests per second, and runs slightly above it because of the checkout share. data/products.json and data/users.json must hold real staging IDs and test-account tokens.

Commands (not executed)

k6 run -e BASE_URL=https://staging-api.shopfictional.dev -e PROFILE=smoke   checkout-load.js
k6 run -e BASE_URL=https://staging-api.shopfictional.dev -e PROFILE=average checkout-load.js
k6 run -e BASE_URL=https://staging-api.shopfictional.dev -e PROFILE=stress  checkout-load.js
k6 run -e BASE_URL=https://staging-api.shopfictional.dev -e PROFILE=spike -e SPIKE_RPS=<agreed> checkout-load.js

k6 exits non-zero when a threshold fails, so the same commands work as a CI gate. Keep a kill switch ready (Ctrl+C, or stopping the generator host) for every run beyond smoke.

How to read the results

Report each threshold next to its measured value (for example, "p95 X ms vs 400 ms"), never "seemed fine". Paste the k6 summary, trimmed to the relevant lines.

Read p50/p90/p95/p99 and the max, not the average. A p50–p99 gap that widens as load climbs points to queuing: pools, locks, GC, or a slow downstream service.

Read errors and latency together. Thresholds are measured on expected_response:true because a 5 ms 500 would otherwise make latency look better.

Watch for a throughput plateau. If req/s stays flat while the configured rate keeps rising, the system has saturated. Find the timestamp and check CPU, memory, DB connections in use, queue depth, and payment-sandbox latency. The first resource to saturate is the finding.

Classify the failure mode: graceful (429s, shedding, queuing with backpressure) or catastrophic (timeout cascades, OOM, restarts). Catastrophic failure at 240 req/s is a fix before Black Friday, not a note.

Check generator health. If dropped_iterations is above zero or the generator's CPU or network was maxed, the run is inconclusive. Discard it and rerun with more capacity; don't report its numbers.

Measure recovery after stress and spike: latency should return to baseline and queues should drain within minutes.

Next steps

1. Answer the six confirmation questions above, especially the real traffic mix and whether staging is shared.
2. Fill data/products.json and data/users.json from staging.
3. Run smoke and share the output; I'll check the script's behavior before any heavy run.
4. After average-load, record the baseline (thresholds, measured percentiles, environment, generator location) in learnings/. That baseline is what the stress run, and every future run, gets compared against.
