React Component State Machine Outliner

1. Machine Overview

A multi-step checkout wizard that moves a user through

cart review → shipping address → payment → success. It supports non-destructive backward navigation (all entered data lives in context and survives step changes) and a payment retry policy: a failed payment can be retried up to 3 times, after which the session is locked and no further payment attempts are possible.

Scope: step navigation, form data retention, payment invocation and failure handling, retry counting, session locking. Out of scope: field-level input validation UI (handled by form libraries), cart editing, and payment-provider UI internals.

2. Context (Extended State)

interface CheckoutContext {
  cart: {
    items: Array<{ id: string; name: string; qty: number; unitPrice: number }>;
    subtotal: number;
  };
  shippingAddress: {
    fullName: string;
    line1: string;
    line2?: string;
    city: string;
    state: string;
    postalCode: string;
    country: string;
    phone?: string;
  } | null;
  paymentDetails: {
    method: 'card' | 'upi' | 'wallet';
    token: string;            // tokenized reference only, never raw card data
    billingSameAsShipping: boolean;
  } | null;
  paymentAttempts: number;    // starts at 0, max 3
  maxPaymentAttempts: number; // constant 3
  lastError: { code: string; message: string } | null;
  orderId: string | null;
  lockedReason: string | null;
}

3. Events

• NEXT: advance from the current step (payload: none; relies on context already updated)
• BACK: return to the previous step (no payload)
• UPDATE_CART: { items: CartItem[] }, sync cart changes in from the outside
• UPDATE_SHIPPING: { address: ShippingAddress }, save form data without leaving the step
• SUBMIT_SHIPPING: { address: ShippingAddress }, save and advance
• UPDATE_PAYMENT: { details: PaymentDetails }, save payment form data
• SUBMIT_PAYMENT: { details: PaymentDetails }, save and start processing
• RETRY_PAYMENT: no payload, retry after a failure
• EDIT_PAYMENT: no payload, return to the payment form after a failure to change details
• RESET: no payload, start a new checkout (only from success or locked, per product decision)

Internal (invoked actor) events: done.invoke.processPayment (output: { orderId }) and error.platform.processPayment (error: { code, message }).

4. State Diagram Outline

• State: checkout (root)

  • Type: compound (parent of the wizard steps; holds the history-preserving behavior)
  • On RESET: Transitions to checkout.cartReview (Guard: none; action resetContext)
  • Entry Actions: none
  • Exit Actions: none

• State: checkout.cartReview

  • Type: initial
  • On UPDATE_CART: Stays (action: assignCart)
  • On NEXT: Transitions to shippingAddress (Guard: cartHasItems)
  • Entry Actions: trackStepViewed('cart')
  • Exit Actions: none

• State: checkout.shippingAddress

  • Type: atomic
  • On UPDATE_SHIPPING: Stays (action: assignShipping)
  • On SUBMIT_SHIPPING: Transitions to payment (Guard: isShippingValid; action: assignShipping)
  • On BACK: Transitions to cartReview (no guard; context untouched)
  • Entry Actions: trackStepViewed('shipping')
  • Exit Actions: none (data already persisted via UPDATE_SHIPPING)

• State: checkout.payment

  • Type: compound (parent of the payment sub-states)
  • Initial child: form

On BACK: Transitions to shippingAddress (Guard: not isProcessing, enforced by only handling BACK on the form child, not on processing)

• Entry Actions: trackStepViewed('payment')

• Exit Actions: none

• State: checkout.payment.form

  • Type: atomic
  • On UPDATE_PAYMENT: Stays (action: assignPayment)

On SUBMIT_PAYMENT: Transitions to processing (Guard: isPaymentValid; actions: assignPayment, incrementAttempts)
- On BACK: Transitions to shippingAddress
- Entry Actions: none
- Exit Actions: none

• State: checkout.payment.processing
  • Type: atomic (invokes processPayment actor)
  • Invoke: processPayment with input { cart, shippingAddress, paymentDetails }
  • On done.invoke.processPayment: Transitions to success (action: assignOrderId)
  • On error.platform.processPayment: Transitions to failed (action: assignError)

On BACK / NEXT / SUBMIT_PAYMENT: Ignored (no handler, which prevents double submission and mid-flight navigation)
- Entry Actions: showProcessingOverlay, clearLastError
- Exit Actions: hideProcessingOverlay

• State: checkout.payment.failed
  • Type: atomic (transient decision point)
  • Always (eventless transitions), evaluated in order:
    1. Transitions to #checkout.locked (Guard: attemptsExhausted, i.e. paymentAttempts >= maxPaymentAttempts; action: assignLockReason)
    2. Otherwise stays and waits for user events

On RETRY_PAYMENT: Transitions to processing (Guard: canRetry, i.e. paymentAttempts < maxPaymentAttempts; action: incrementAttempts)
- On EDIT_PAYMENT: Transitions to form (Guard: canRetry)
- On BACK: Transitions to form (Guard: canRetry)
- Entry Actions: showPaymentErrorBanner, trackPaymentFailure
- Exit Actions: dismissPaymentErrorBanner

• State: checkout.success
  • Type: final
  • On RESET: Transitions to cartReview (action: resetContext)

Entry Actions: clearPaymentDetails (purge token from context), trackOrderCompleted, clearPersistedCheckout

• Exit Actions: none

• Note: no BACK handler, so the user cannot return to payment after a completed order.

• State: checkout.locked

  • Type: final (terminal for this session)

On RESET: Transitions to cartReview (Guard: lockExpired or an explicit support/new-session policy; action: resetContext)

Entry Actions: clearPaymentDetails, showLockedMessage, notifyBackend('session_locked'), trackSessionLocked

• Exit Actions: none
• Note: all payment events are intentionally unhandled here.

Attempt counting note: incrementAttempts runs on every transition into processing (first submit and each retry), so after the third failed attempt paymentAttempts === 3, the attemptsExhausted guard passes, and the session locks. If your product definition is "initial try plus 3 retries" (4 total), set maxPaymentAttempts to 4.

5. Implementation Notes

Keep step data in context, not in component state. Because every UPDATE_* event writes to context, the BACK transitions need no special logic and no history state. Components should read defaults from snapshot.context so returning to a step repopulates the form. For refresh resilience, persist the snapshot with actor.getPersistedSnapshot() to sessionStorage and rehydrate via createActor(machine, { snapshot }). Exclude paymentDetails.token from persistence.

2. Model the payment call as an invoked actor with fromPromise. Use setup({ types, guards, actions, actors }) for typed XState v5 code, e.g. processPayment: fromPromise(({ input, signal }) => api.pay(input, { signal })), and pass an idempotency key (derive it from cart plus the attempt number) so a retry after a network timeout cannot double-charge. Because processing ignores BACK, double submits and mid-flight navigation are impossible by construction; also disable the buttons from snapshot.matches({ payment: 'processing' }).

3. Drive the UI from snapshot.matches and derive flags with selectors. Use useSelector(actor, s => s.matches(...)) to render each step, and compute values like attemptsRemaining = max - paymentAttempts for the retry banner. Enforce the lock server-side as well (notifyBackend('session_locked')), because a client-side lock can be bypassed by reloading or clearing storage.
