    Clean Architecture

    1

    Name: clean-architecture description: Apply Robert C.

    Free

    1 installSecurity scanned

    Clean Architecture

    Example session with this skill installed

    Review this TypeScript controller for Clean Architecture violations and suggest a refactor: it takes an Express req, saves to TypeORM directly, and sends a welcome email.

    • Read your context and instructions
    • Compiled the clean architecture

    I have analyzed the UserController. This is a

    Tier 2 task (New Feature/Module logic). The current implementation violates the Dependency Rule by coupling the controller (Layer 3) directly to the ORM and External Mailer (Layer 4).

    Architectural Audit

    PrincipleStatusObservation
    Dependency Rule❌ FailController imports TypeORM and Nodemailer directly.
    SRP❌ FailController handles HTTP, database persistence, and notification logic.
    DIP❌ FailDepends on concrete implementations rather than abstractions.

    Refactored Implementation

    // Layer 1: Entity
export class User {
  constructor(public readonly email: string, public readonly id?: string) {}
}

// Layer 2: Ports (Interfaces)
export interface IUserRepository {
  save(user: User): Promise<void>;
}

export interface IMailService {
  sendWelcome(email: string): Promise<void>;
}

// Layer 2: Use Case (Interactor)
export class RegisterUserUseCase {
  constructor(
    private userRepository: IUserRepository,
    private mailService: IMailService
  ) {}

  async execute(email: string): Promise<void> {
    const user = new User(email);
    await this.userRepository.save(user);
    await this.mailService.sendWelcome(user.email);
  }
}

// Layer 3: Adapter (Controller)
export class UserController {
  constructor(private useCase: RegisterUserUseCase) {}

  async handle(req: Request, res: Response) {
    const { email } = req.body;
    await this.useCase.execute(email);
    res.status(201).send();
  }
}

    Next steps

    1. Implement the IUserRepository using your TypeORM repository in the Infrastructure layer.
    2. Setup the Composition Root to inject the concrete Nodemailer implementation into the Use Case.
    3. Add a Result type to the Use Case to handle domain-specific errors without leaking 500 status codes.

    Connects securely to your tools. The creator never sees your data.

    About this skill

    Name: clean-architecture description: Apply Robert C. Martin's Clean Architecture, SOLID, and component-decoupling principles when designing, reviewing, or refactoring code — scaled correctly to the size of the task so trivial changes don't get over-engineered. Use this whenever the user asks to design a new feature/service, review code for architectural soundness, refactor toward better layering/testability, decide where a piece of logic belongs (domain vs. use case vs. controller vs. infrastructure), untangle a legacy/brownfield codebase, or explicitly mentions "clean architecture", "hexagonal architecture", "ports and adapters", "onion architecture", "SOLID principles", "dependency inversion", or "separation of concerns". Also trigger when the user is unsure whether a design decision belongs in one layer or another, or asks "is this a violation of X principle".

    Clean Architecture Engine

    A practical, calibrated skill for applying Clean Architecture — scaled to task size, grounded in real code, honest about framework compromises, and explicit about error handling, cross-cutting concerns, legacy code, and when not to apply any of this.

    Read references/ files as needed — don't load all of them up front.** Each is pointed to below with a note on when it's relevant.

    1. Classify the task first (always do this before anything else)
    Task SizeExampleWhat to apply
    Tier 0 — TrivialTypo, log message, constant change, off-by-one fixJust fix it. No layers, no ceremony.
    Tier 1 — Small changeAdd a field to an existing DTO, new endpoint reusing an existing Use Case, bug fix inside one layerRespect existing boundaries. No new layers/folders, no 5-step workflow.
    Tier 2 — New feature/moduleNew CRUD feature, new integration, new workflowFull layer separation (Section 2) + workflow (Section 5), scaled file granularity — see references/file-granularity.md.
    Tier 3 — New system/serviceGreenfield service, major subsystem, long-lived architectural decisionEverything: full layering, SOLID review, verification table (references/verification.md), trade-off discussion.

    Before applying anything else, also check Section 6 ("When NOT to apply this")** — a one-off script, a throwaway prototype, or a single-maintainer tool with no growth plan may not need any of this. Say so plainly if that's the case; don't silently over-architect.

    If unsure which tier applies, default one tier lower than your first instinct and let the person ask for more rigor.

    The failure mode this exists to prevent: Tier 3 ceremony on a Tier 0 fix. A process that makes small changes expensive violates Clean Architecture's own stated goal — minimizing the cost of change over time.

    1. Core philosophy

    Primary objective: minimize the human cost of building and maintaining the system over time — not maximize adherence to a diagram. Primary value: architecture over behavior. Behavior changes easily if the architecture stays flexible ("soft"). Deferral of details: high-level policy (business rules) must not depend on low-level detail (frameworks, databases, web servers, UI, message brokers). Pragmatism over purity: every rule below has documented exceptions (references/framework-exceptions.md). A rule with no acknowledged exceptions usually hasn't met a real framework yet.

    1. The four layers
    +-----------------------------------------------------------------------+
|  4. Frameworks & Drivers Layer (Web, DB, UI, External APIs, Devices) |
|   +---------------------------------------------------------------+   |
|   |  3. Interface Adapters Layer (Controllers, Gateways, Mappers) |   |
|   |   +-------------------------------------------------------+   |   |
|   |   |  2. Application Business Rules (Use Cases & Ports)   |   |   |
|   |   |   +-----------------------------------------------+   |   |   |
|   |   |   |  1. Enterprise Business Rules (Entities)      |   |   |   |
|   |   |   +-----------------------------------------------+   |   |   |
|   |   +-------------------------------------------------------+   |   |
|   +---------------------------------------------------------------+   |
+-----------------------------------------------------------------------+

⭕ The Dependency Rule
> **Source code dependencies must point ONLY inward.** Nothing in an inner circle may know anything about an outer circle — no classes, functions, variables, data formats, or framework imports.

Layer 1 — Entities:** core business concepts, invariants that hold regardless of which application uses them. No framework imports, no DB/HTTP dependencies, no references to outer layers.

Layer 2 — Use Cases:** orchestrates data flow to/from Entities for an application-specific goal. Interactors, input/output ports (interfaces), request/response DTOs. No ORM/DB framework references, no web/HTTP objects (`req`, `res`, `HttpContext`), no concrete outer-layer implementations.

Layer 3 — Interface Adapters:** translates between Use Case/Entity shapes and external agency shapes. Controllers, presenters, view models, repository implementations, mappers.

Layer 4 — Frameworks & Drivers:** the glue — routing, ORM config, DB drivers, UI libraries. Kept at the outer edge; frameworks are details, not the architecture.

For full multi-language code examples (TypeScript, C#, Python) of every layer, plus a before/after fix of the "Smart Controller" anti-pattern → read `references/code-examples.md`.**


3. SOLID & component principles

1. **SRP** — one module answers to one actor/stakeholder.
2. **OCP** — extend via interfaces/polymorphism; don't edit core code for new behavior.
3. **LSP** — subtypes substitutable for base types; throwing `NotImplementedException` in an override is a violation.
4. **ISP** — small, focused interfaces over large monolithic ones.
5. **DIP** — high-level modules depend on abstractions, not low-level modules.

Component coupling:** ADP (no dependency cycles), SDP (depend toward stability), SAP (abstractness matches stability).


4. Prohibitions — flag and reject

1. ❌ **Boundary leak** — e.g. `UseCase` importing `SqlUserRepository` instead of `IUserRepository`.
2. ❌ **Leaky ORM entities** used as domain models.
3. ❌ **Smart controllers / fat views** — business logic in a controller or UI event handler.
4. ❌ **HTTP context pollution** — `req`/`res`/`HttpContext` passed into Use Cases or Entities.
5. ❌ **Primitive obsession across boundaries** — raw JSON/strings instead of typed DTOs/Value Objects.
6. ❌ **Circular dependencies.**



5. Execution workflow (Tier 2/3 only)

1. Define Entities & Value Objects (Layer 1).
2. Define Application Ports & DTOs (Layer 2).
3. Implement Use Case Interactors (Layer 2), relying only on Layer 1/2 abstractions.
4. Implement Interface Adapters & Infrastructure (Layers 3 & 4).
5. Wire dependencies at the Composition Root.

Tier 1: skip straight to the layer the change belongs in — don't re-run all five steps for a one-field addition.

Directory structure should announce what the system does, not its framework** (Screaming Architecture) — e.g. `src/Ordering/{Domain,Application,Infrastructure,Presentation}/`, not `src/{Models,Views,Controllers,Services}/`. Never restructure an existing module's folders for a Tier 0/1 fix.

6. When NOT to apply this skill

Clean Architecture has a real cost: more files, more indirection, more upfront design. Skip most/all of it for:
- One-off scripts, data migrations run once, throwaway prototypes.
- A true MVP/spike explicitly built to validate an idea before a scale-or-rewrite decision.
- Small internal tools with a single maintainer, low change frequency, no growth plan.

If a person asks to "apply Clean Architecture" to something in these categories, say plainly that the overhead likely isn't worth it, offer a lighter-weight alternative (a single well-organized module, clear function boundaries, no ports/DI), and let them decide.

7. Legacy code, conflicts, and topics needing more depth

Several situations need more than this file's core rules — **read the relevant reference before acting**:

-Working inside an existing legacy/brownfield codebase**, or a codebase whose existing style directly contradicts Clean Architecture → `references/legacy-and-conflicts.md` (Strangler Fig pattern, "clean island" approach, anti-scope-creep rules).
-Error handling across layers** (exceptions vs. Result/Either types, where transport-specific errors get translated) → `references/error-handling.md`.
-Cross-cutting concerns** — transactions/Unit of Work, logging, caching, authorization — where do they belong? → `references/cross-cutting-concerns.md`.
-Domain Events / async workflows** (e.g. "when an order is submitted, notify a different part of the system") → `references/domain-events.md`.
-Evolving a Port's interface without breaking every implementer** → `references/port-versioning.md`.
-Avoiding duplicated validation logic across multiple Use Cases** → `references/shared-validation.md`.
-How many files a small feature actually needs** (don't over-fragment a 15-line feature into 6 files) → `references/file-granularity.md`.
-What to do when you (the AI agent) spot a violation** — flag vs. silently fix vs. escalate → `references/authority-model.md`.
-Structuring a full Tier 2/3 response with a real verification table** (cited evidence, not bare Pass/Fail) → `references/verification.md`.

Appendix — noted but out of scope

Deliberately excluded to keep this skill usable by any programmer rather than DDD specialists: architectural maturity metrics (coupling/instability numbers with thresholds), Aggregate boundary sizing at the full DDD level, and multi-service/microservice Bounded Context boundary-drawing. These are real, deeper questions — but one level above general Clean Architecture.
